KSCAN-X 3D scanner
Powered by SCANOLOGY’s advanced wireless technology and adaptive photogrammetry, the KSCAN-X is an intelligent, wireless large-area 3D scanner that sets a new standard for large-scale 3D measurements.
Featuring wireless operation, ultra-wide scanning area, extended depth of field, and fast scanning, the KSCAN-X offers smooth and high-precision 3D measurements for ultra-large and large to medium-sized parts across industries such as aerospace, heavy industry, and rail transportation.
SCANOLOGY's metrology laboratory comply with ISO/IEC 17025 standards.
Sariki is SCANOLOGY'S MASTER RESELLER for Spain and Portugal
Ideal 3D scanning solution: KSCAN-X
Truly Wireless Scanning
It operates completely wire-free, enabling seamless scanning even in power-limited environments, at heights, or in remote locations. Experience true wireless freedom in 3D measurement
Robust on-board processing module
Handle large amounts of data efficiently
Dual-battery system
Ensures no-cable and continuous operations
Dual-WNIC design technology
Guarantees wireless, stable, and high-speed data transfer
Ultra-large Scanning Area
KSCAN-X, powered by our in-house developed and sophisticated algorithms, offers extensive scanning area of up to 2.6mx1.8m, which is ideal for scanning ultra-large parts.
Ultra-large Depth of field
With a large depth of field ranging from 0.3-2.5m, KSCAN-X ensures precise measurements for everything from medium to ultra-large parts with exceptional quality. Its flexible working distance makes scanning various-sized parts easier and more efficient.
Adaptive photogrammetry
Con un avanzado sistema de fotogrametría adaptativa, KSCAN-X garantiza una precisión excepcional en largas distancias. Elimina los errores acumulativos y garantiza una precisión volumétrica consistente, proporcionando resultados de alta precisión tanto para mediciones de gran escala como detalladas, incluso en entornos desafiantes.
Power and comfort in a single design.
-The well‑structured visual frame highlights key components such as the camera lens and the laser system, making operation seamless.
-Diseñado para la comodidad y la eficiencia, garantiza un agarre seguro y un uso sin fatiga, incluso durante largas sesiones de escaneo.
-Designed with ergonomics and aesthetics in mind, the KSCAN‑X combines crisp, dynamic lines with a balanced and intuitive design.
Benefits
Built-In Touchscreen
ultra-fast
scanning rate
Smart
Guidance
Wide scanning area
Related Products and Services
With this system you can use different softwares depending on your needs and uses.
We will always advise you about the most appropriate complement for your company if you wish. Do not hesitate to ask us.
Applications
You can use the KSCAN-X scanner in applications for Design and Manufacturing (Reverse Engineering, Rapid Prototyping, 3D Documentation, 3D Printing), Quality Department (Dimensional Control, Deformation Analysis, Repeatability Analysis), Health (Orthopedics, Prosthetics, Surgery Plastic Arts), Science and Art (Research, Train, Virtual Museums, Heritage Preservation, Architecture) and Video Games (Avatars, 3D Scenes, 3D Printing).
Quality control
Compare your measurements with the nominal CAD of the part and create a 3D color mapping with the errors
Analysis
Identify and find solutions to any structural and functional defect by modeling the system or product in a virtual environment
Reverse engineering
Perform reverse engineering from the obtained point cloud (free form geometry and surfaces) and transform it into a native CAD model
3D printing
Manufacture detailed parts in various materials with perfect data integration with any 3D printer
Technical specifications
| 3D scanner | KSCAN-X 3D scanner |
|---|---|
| Large FOV scanning | 84 blue laser lines |
| Medium-distance scanning | 54 blue laser lines |
| Deep hole scanning | 1 extra blue laser line |
| Photogrammetry | Adaptive photogrammetry |
| Volume accuracy | 0,075 mm + 0,010 mm/m |
| Resolution | 0,1 mm |
| Scanning rate | 6,450,000 measurements/s |
| Scanning area | 2600 mm x 1800 mm |
