3DeVOK MT scanner
The 3DeVOK MT is a professional and versatile 3D scanner that stands out for its exceptional performance. Based on industrial-grade 3D scanning technology, it incorporates both lasers and speckles to offer you a magic tool. With professional scanning software, flexible parameter settings, intuitive interaction, and reliable performance, it significantly enhances work efficiency. It is an excellent solution for scanning objects of almost any kind, making it ideal for artistic design, reverse engineering, 3D measurement, 3D visualization, 3D printing, research, education and more.
Key Features: Efficient scanning with 34 blue laser lines, Marker-free scanning with laser modes, Smart combination of large-area infrared speckle and partial fine scanning, Advanced hybrid alignment, Invisible light scanning, Easy scanning for black and reflective objects without spray, Outdoor scanning.
Compliant with ISO 10360, the 3DeVOK ensures results you can trust worldwide.
Sariki is SCANOLOGY'S MASTER RESELLER for Spain and Portugal
Ideal 3D scanning solution: 3DeVOK MT
Industrial & Automotive Parts / Product Design
Marker Alignment with 34-line blue laser & 22-line infrared laser
- High Data Quality: Accuracy reaching 0.04 mm, resolution up to 0.05 mm
- Strong Material Adaptability: Capture black and reflective surfaces without scanning spray
- Fast Scanning: Frame rates up to 70 FPS while a maximum single-frame scanning area of 490 mm × 490 mm
- Efficient Operation: Marker distance of 10-12 cm, reducing marker usage
- Real-time Scanning: New real-time mesh display algorithm for easy monitoring of scan results
- 3D Data Compatibility: Support export of formats like .asc and .stl, compatible with mainstream CAD and reverse engineering software
- Recommended Object Size: 0.05–5 m
- Applications: CAD design, reverse engineering, automotive customization, 3D printing, virtual simulation, and more
Art Sculptures / Movable Cultural Relics
Hybrid Alignment with 34 blue laser lines & 22 infrared laser lines
- Marker-free Scanning: Direct scanning of objects with rich textures or geometric features
- Fine Details: Resolution up to 0.1 mm
- Strong Material Adaptability: Easily handle dark, black, and reflective surfaces
- Stable Lighting Adaptability: Ensure smooth data acquisition in both low light and direct sunlight
- Recommended Scanning Size: 0.1–4 m
- Applications: Suitable for 3D art design, cultural and creative product design, and digital archiving/restoration/monitoring/preservation of cultural relics
High-Definition Full-Color Mapping Solution
- Comprehensive Workflow: Combine MT color 3D scanning with free texture mapping or optional advanced 3D texturing software to capture precise and vivid 3D color data
- Ideal Objects: Suitable for items with intricate textures and vibrant colors
- Applications: Perfect for 3D visualization, full-color 3D printing, cultural heritage data archiving, and more
* Enhanced 3D Data Display with Color Scanning and Texture Mapping
Medium to Large Objects / Sculptures / Full-Body Scans
Large-area Infrared Speckle + Partial Fine Scanning with 3 Light Sources
- Powerful Alignment Capability: Large-area infrared speckle scanning covers up to 1,100 mm*1,000 mm per frame, efficiently accommodating medium to large objects
- Partial Fine Scanning: Supports seamless mode switching and data integration, allowing smooth scanning of larger objects while preserving intricate details (resolution up to 0.1 mm).
- Large Depth of Filed: Scanning distance from 150 to 1,500 mm enables versatile, multi-angle scanning for comprehensive data capture
- Maximum Scanning Size: up to 5m
Full-Body / Body Parts Scanning
Infrared Speckle + Geometry / Hybrid Alignment
- Human Body Mode: Supports no-light scanning, hair capture, and automatic correction of slight movements
- Eye-Safety: Class I laser compliant with IEC 60825 standards, ensuring safe operation
- Exceptional Detail: Resolution up to 0.1 mm for sharp and clear details
- Easy Operation: Maximum scanning area of 1,100 mm × 1,000 mm for smooth scanning
- Strong Adaptability: No need for exposure adjustments, making it easy to scan dark clothing
- Applications: Ideal for medical rehabilitation, artistic design, personalized customization, and more.
Research / Education
- Versatile Coverage: Accommodates a wide range of object sizes, from 0.05 m to 5 m
- Environmental Compatibility: Adapts seamlessly to both indoor and outdoor scanning conditions
- Multidisciplinary Applications: Supports diverse fields, including industrial design, mechanical design, art, cultural heritage and archaeology, medical rehabilitation, and forensic science.
- Education-Friendly & Professional Support: Scanning software with no node limitations, plus exclusive educational discounts, offering a cost-effective 3D solution tailored for research and teaching
Benefits
professional scanner
Precisión hasta 0.04 mm
Texture capture
Applications
It is an excellent solution for scanning objects of almost any kind, making it ideal for artistic design, reverse engineering, 3D measurement, 3D visualization, 3D printing, research, education and more.
Quality control
Compare your measurements with the nominal CAD of the part and create a 3D color mapping with the errors
Analysis
Identify and find solutions to any structural and functional defect by modeling the system or product in a virtual environment
Reverse engineering
Perform reverse engineering from the obtained point cloud (free form geometry and surfaces) and transform it into a native CAD model
3D printing
Manufacture detailed parts in various materials with perfect data integration with any 3D printer
Technical specifications
| 3D scanner | 3DeVOK |
|---|---|
| Light Sources | 34 Blue Laser Lines / 22 Infrared Laser Lines [invisible] /Infrared VCSEL Structured Light [invisible] |
| Basic Accuracy | Up to 0.04 mm |
| Volume accuracy | Up to 0.04 mm + 0.06 mm/m |
| Ability to Capture Texture | YES |
| Scanning Distance | 150 - 1000 mm / 150 - 1500 mm |
| Scanning Speed | Up to 3,300,000 points/s -Up to 2,450,000 points/s- Up to 4,500,000 points/s |
| Output Formats | *.obj, *.stl, *caply, *.asc, *.mk2, *. txt, *. epj, *. apj, *. spj, *. mapa, *sk |
